Product Specifications
Model | WSZ-6601 |
Electricity | Single phase,110V/220V |
Power | 0.8kw |
Sealing Size | 2 inches sealing size: L=150~∞ mm, W=110~500mm, H=110~500mm 3 inches sealing size: L=150~∞ mm, W=135~500mm, H=110~500mm |
Conveyor Belt Size | W=50mm |
Work Surface Height | 570~770 mm |
Transfer Speed | 20M / minute |
Machine Size | 1250(L) x 960(W) x 1420(H) mm |
Features
1. Drive belts on both sides, suitable for narrower cartons.
2. The height of the table can be adjusted with the front and rear conveyors.
3. A new design with a seat on the top, which automatically adjusts the unevenness of the carton.
Product Specifications
Model | WSZ-6601A |
Electricity | Single phase,110V/220V/240V, 50/60HZ |
Power | 0.8kw |
Sealing Size | 2 inches sealing size: L =150~∞ mm, W =130~500mm, H =120~500mm 3 inches sealing size: L =150 ~∞mm, W =155~500mm, H =120~500mm |
Conveyor Belt Size | W=50mm |
Work Surface Height | 570~770 mm |
Transfer Speed | 20M / minute |
Machine Size | 1250(L) x 910(W) x 1315(H) mm |
Air Pressure Demand | 6 KG/cm |
Features
1. Automatically adjust the height and width for cartons of different specifications.
2. Drive belts on both sides, suitable for narrower cartons.
3. Left and right drive, automatic positioning for wide and narrow cylinders, use with the production line process.
4. The height of the table can be adjusted with the front and rear conveyors.
Product Specifications
Model | WSZ-6601S |
Electricity | Single phase,110V/220V/240V, 50/60HZ |
Power | 0.8kw |
Sealing Size | 2 inches sealing size: L =150 ~∞mm, W =110~500mm, H =120~500mm 3 inches sealing size: L =150 ~∞mm, W =135~500mm, H =120~500mm |
Work Surface Height | 570~770 mm |
Transfer Speed | 20M / minute |
Machine Size | 1250(L) x 960(W) x 1150(H) mm |
Features
1. Left and right drive, column lift, wide and narrow, high and low, with manual bar adjustment.
Product Specifications
Model | WSZ-6602 |
Electricity | Single phase,110V/200V/220V/230V/240V, 50/60HZ |
Power | 0.8kw |
Sealing Size | 2 inches sealing size: L =150~∞ mm, W =180~500mm, H =110~500mm 3 inches sealing size: L =150~∞ mm, W =180~500mm, H =110~500mm |
Work Surface Height | 570~770 mm |
Transfer Speed | 20M / minute |
Machine Size | 1105(L) x 785(W) x 1420(H) mm |
Features
1. This machine is driven by upper and lower motors and is suitable for higher cartons.
2. Left and right auxiliary clamp rail device, can be correctly aligned with the center to ensure carton transport.
3. The new design adhesive tape holder can be used to apply tape with different flexibility of workpiece.
4. Easy to adjust the tension of the tape dispenser, suitable for all kinds of cartons.
5. Workbench can be adjusted.
Product Specifications
Model | WSZ-6603 |
Electricity | Single phase,110V/220V/240V, 50/60HZ |
Power | 0.8kw |
Sealing Size | 2 inches sealing size: L =150~∞ mm, W =180~500mm, H =110~500mm 3 inches sealing size: L =150 ~∞mm, W =155~500mm, H =110~500mm |
Work Surface Height | 570~770 mm |
Transfer Speed | 20M / minute |
Machine Size | 1250(L) x 960(W) x 1420(H) mm |
Features
1. Upper and side belt drive for heavy carton use.
2. Easy manual adjustment of width, and the sealing size can be changed at any time.
3. The height of the workbench can be adjusted to the needed height.
Product Specifications
Model | WSZ-6603A |
Electricity | Single phase,110V/220V/240V, 50/60HZ |
Power | 0.8kw |
Sealing Size | 2 inches sealing size: L =150~∞mm, W =130~500mm, H =120~500mm 3 inches sealing size: L =150~∞mm, W =155~500mm, H =120~500mm |
Work Surface Height | 5570~770 mm |
Transfer Speed | 20M / minute |
Machine Size | 1250(L) x 910(W) x 1315(H) mm |
Air Pressure Demand | 6 KG/cm2 |
Features
1. Upper and side belt drive for heavy carton use.
2. Automatically adjust the height and width for cartons of different specifications.
3. The height of the workbench can be adjusted to the needed height.
4. Side drive, automatic correction adjustment, sealing, smooth operation.
Product Specifications
Model | WSZ-6604 |
Electricity | Single phase,110V/220V/240V, 50/60HZ |
Power | 0.8kw |
Sealing Size | 2 inches sealing size: L =150~∞mm, W =250~600mm, H =110~250mm 3 inches sealing size: L =150~∞mm, W =250~600mm, H =135~250mm |
Work Surface Height | 570~770 mm |
Transfer Speed | 20M / minute |
Machine Size | 1180(L) x 930(W) x 1150(H) mm |
Features
1. Driven by upper and lower motor for flat carton and Styrofoam case.
2. Easy operation, standardized parts supply.
Product Specifications
Model | WSZ-6605S |
Electricity | Single phase,110V/220V/240V, 50/60HZ |
Power | 0.8kw |
Sealing Size | 2 inches sealing size: L =200~600mm, W =130~500mm, H =120~500mm 3 inches sealing size: L =200~600mm, W =150~500mm, H=120~500mm |
Work Surface Height | 570~770 mm |
Transfer Speed | 20M / minute |
Machine Size | 1900(L) x 960(W) x 1600(H) mm |
Air Pressure Demand | 4-6 KG/cm2 |
Features
1. Suitable for production lines with simple carton size.
2. After the carton is fed in, the front cover, the back cover and the side covers of the carton can be automatically folded in, and the tape is applied and the output proceeds smoothly.
3. The height and width of the carton are adjusted by the screw and the adjustment is easy.
4. Belt drive on both sides.
Product Specifications
Model | WSZ-6605 |
Electricity | Single phase,110V/220V/240V, 50/60HZ |
Power | 0.8kw |
Sealing Size | 2 inches sealing size: L =150~600mm, W =160~500mm, H =110~500mm 3 inches sealing size: L =150~600mm, W =160~500mm, H =110~500mm |
Work Surface Height | 570~770 mm |
Transfer Speed | 20M / minute |
Machine Size | 1960(L) x 930(W) x 1650(H) mm |
Air Pressure Demand | 4-6 KG/cm2 |
Features
1. Suitable for production lines with heavy carton weight and simple carton size.
2. After the carton is fed in, the front cover, the back cover and the side covers of the carton can be automatically folded in, and the tape is applied and the output proceeds smoothly.
3. Belt drive on both sides + upper belt drive.
4. The height and width of the carton are adjusted by the screw and the adjustment is easy.
Product Specifications
Model | WSZ-6702 |
Electricity | Single phase,220V/240V, 50/60HZ |
Power | 0.8kw |
Sealing Size | 3 inches sealing size: L =280~700mm,W=200~600mm, H=200~600mm |
Work Surface Height | 570~770 mm |
Transfer Speed | 20M / minute |
Machine Size | 2100(L) x 1470(W) x 1500(H) mm |
Air Pressure Demand | 6 KG/cm |
Features
1. Suitable for production line with simple carton size.
2. The height and width of the carton are easily adjusted, and the crank handle can be gently adjusted to obtain the required size.
Product Specifications
Model | WSZ-6702A |
Electricity | Single phase,110V/220V/240V, 50/60HZ |
Sealing Size | Single phase,110V/220V/240V, 50/60HZ |
Work Surface Height | 570~770 mm |
Transfer Speed | 20M / minute |
Machine Size | 280-630(L) x 250-600(W) x 225-600(H) mm |
Air Pressure Demand | 6 KG/cm2 |
Features
1. Most suitable for variable carton sizes, suitable for many automated production lines.
2. Wide and narrow, high and low with fully automatic air pressure adjustment.
3. After the carton is sealed by the upper and middle tapes of the front carton sealing machine, it enters the corner sealing machine, and the upper and lower four corner seals are smoothly flatten.
Product Specifications
Model | WSZ-6606 |
Electricity | Single phase,110V/220V/240V, 50/60HZ |
Minimum Carton Size | 300(L) x 230(W) x 600(H) mm |
Maximum Carton Size | 600(L) x 230(W) x 600(H) mm |
Machine Size | 1300(L) x 870(W) x 1500(H) mm |
Air Pressure Demand | 4-6 KG/cm2 |
Features
1. Suitable for empty carton.
2. Manually open carton and place it on the platform, the carton automatically folds and advances to sealing.
